TSC TDP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 33 Copyright 2013 All Rights Reserved.
 DISPLAY
Description
This command can show the image, which is in printer’s image buffer, on LCD panel.
Syntax
DISPLAY IMAGE/OFF
Parameter
Description
Show the image in printer’s image buffer on LCD panel.
OFF
Disable this function.
Note:
 This command has been supported since V6.39 EZ and later firmware.
 This command only can be performed on the printer with LCD display.
Example
Sample code
CLS
TEXT 1,10,"1",0,1,1,"Image on LCD"
TEXT 1,30,"1",0,1,1,"1234567890"
DISPLAY IMAGE
DELAY 5000
DISPLAY OFF
Result

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
