 REFERENCE

Description

This command defines the reference point of the label. The reference (origin) point varies with the

print direction, as shown:

Syntax

REFERENCE x, y

Parameter

Description

Horizontal coordinate (in dots)

Vertical coordinate (in dots)

Note:

200 DPI: 1 mm = 8 dots

300 DPI: 1 mm = 12 dots

Example

Sample code

REFERENCE 10,10
