 WLAN PORT

Description

This command is used to specify the PORT number of Wi-Fi module. Restart the printer is necessary.

Syntax

WLAN PORT number

Parameter

Description

number

Base raw port number. Default is 9100.

Example

Sample code

WLAN MODE INFRASTRUCTURE

WLAN SSID "TEST-AP"

WLAN WPA "123456789"

WLAN IP "10.0.10.138","255.255.255.0","10.0.10.252"

WLAN PORT 8000

SELFTEST WLAN

Result
