TSC TDP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. VII Copyright 2013 All Rights Reserved.
Paper feed direction
DIRECTION 0
Label origin (0,0)
X
Y
X=7mm
Y=3mm
Object Position Calculation
Note :
1. 203 DPI, 1mm=8 dots ; 300 DPI, 1mm=11.8 dots
2. Only integer portion will be used. Ex. 2 mm = 23.6 dots then 23 dots will be used.
DIRECTION 0
CLS
TEXT 56,24,"3",0,1,1,"ABC"
PRINT 1

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
