TSC TDP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 45 Copyright 2013 All Rights Reserved.
 CIRCLE
Description
This command draws a circle on the label.
Syntax
CIRCLE X_start,Y_start,diameter,thickness
Parameter
Description
X_start
Specify x-coordinate of upper left corner (in dots)
Y_start
Specify y-coordinate of upper left corner (in dots)
diameter
Specify the diameter of the circle (in dots)
thickness
Thickness of the circle (in dots)
Example
Sample code
SIZE 80 mm,30 mm
GAP 0,0
DIRECTION 1
CLS
BAR 250,20,100,1
BAR 250,20,1,100
CIRCLE 250,20,100,5
PRINT 1
Result

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
