TSC TDP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 27 Copyright 2013 All Rights Reserved.
 CUT
Description
This command activates the cutter to immediately cut the labels without back feeding the label.
Syntax
CUT
Parameter
Description
None
N/A
Example
Sample code
SIZE 3,3
GAP 0,0
CLS
BOX 0,0,866,866,5
TEXT 100,100,"5",0,1,1,"FEED & CUT"
TEXT 100,200,"5",0,1,1,"300 DPI"
PRINT 1,1
FEED 260
CUT
See Also
SET CUTTER, SET BACK, SET PARTITAL_CUTTER

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
