TSC TDP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 230 Copyright 2013 All Rights Reserved.
 WLAN WPA
Description
This command is used to set WPA security mode. This command only can be set but not be checked.
Restart the printer is necessary.
Syntax
WLAN WPA OFF
WLAN WPA "key"
Parameter
Description
OFF
Disable WPA security mode.
key
The network security key. 8 to 63 characters.
key = Passphrase or Pre-Shared Key
(Passphrase is a string containing between 8 and 63 characters)
(Pre-Shared Key is a 32-byte key, formatted as hexadecimal number)
Example
Sample code
WLAN WPA OFF
WLAN WPA "123456789"

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
