TSC TDP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 42 Copyright 2013 All Rights Reserved.
 BITMAP
Description
This command draws bitmap images (as opposed to BMP graphic files).
Syntax
BITMAP X,Y,width,height,mode,bitmap data…
Parameter
Description
X
Specify the x-coordinate
Y
Specify the y-coordinate
width
Image width (in bytes)
height
Image height (in dots)
mode
Graphic modes listed below:
0: OVERWRITE
1: OR
2: XOR
bitmap data
Bitmap data
Example
 X size 2 bytes

Y size 16 dots
1-byte
2-byte

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
