TSC TDP-247 Programming Manual

TSC AUTO ID Technology Co., Ltd. 43 Copyright 2013 All Rights Reserved.
X - axis
Y- axis
1-byte
2-byte
Binary
Hexadecimal
Binary
Hexadecimal
1
00000000
00
00000000
00
2
00000000
00
00000000
00
3
00000000
00
00000000
00
4
00000111
07
11111111
FF
5
00000011
03
11111111
FF
6
00010001
11
11111111
FF
7
00011000
18
11111111
FF
8
00011100
1C
01111111
7F
9
00011110
1E
00111111
3F
10
00011111
1F
00011111
1F
11
00011111
1F
10001111
8F
12
00011111
1F
11000111
C7
13
00011111
1F
11100011
E3
14
00011111
1F
11110111
F7
15
00011111
1F
11111111
FF
16
00011111
1F
11111111
FF
Sample Code (ASCII)
Hexadecimal
Result
SIZE 4,2
GAP 0,0
CLS
BITMAP 200,200,2,16,0,
• -?-
PRINT 1,1
53 49 5A 45 20 34 2C 32 0D
0A 47 41 50 20 30 2C 30 0D
0A 43 4C 53 0D 0A 42 49 54
4D 41 50 20 32 30 30 2C 32 30
30 2C 32 2C 31 36 2C 30 2C 00
00 00 00 00 00 07 FF 03 FF 11
FF 18 FF 1C 7F 1E 3F 1F 1F 1F
8F 1F C7 1F E3 1F E7 1F FF 1F
FF 0D 0A 50 52 49 4E 54 20 31
2C 31 0D 0A
See Also
PUTBMP, PUTPCX

TSC TDP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
