Example

Downloading BMP file into printer by DiagTool

Sample Code

SPEED 2

DENSITY 3

SIZE 4,1.5

GAP 0,0

DIRECTION 1

CLS

PUTBMP 10,10,"SAMPLE.BMP"

BLOCK 10,180,240,100,"2",0,1,1,"bpp and contrast are omitted."

PUTBMP 300,10," SAMPLE.BMP",1,80

BLOCK 300,180,240,100,"2",0,1,1,"bpp = 1

contrast = 80"

PUTBMP 590,10," SAMPLE.BMP",8,80

BLOCK 590,180,240,100,"2",0,1,1,"bpp = 8

contrast = 80"

PRINT 1

Result

Other manuals for TSC TDP-247

Questions and Answers:

Need help?

Do you have a question about the TSC TDP-247 and is the answer not in the manual?

General

Print Method	Thermal Transfer / Direct Thermal
Communication Interface	USB 2.0, RS-232
Power Supply	100-240V AC, 50/60 Hz
Operating Temperature	41°F - 104°F (5°C - 40°C)
Operating Humidity	85% non-condensing
Max. Print Width	4.09" (104 mm)
Label Width	1.18" - 4.33" (30 mm - 110 mm)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
