TSC TTP-245 Service Manual

TTP-245 / TTP-343
96
9.5.2 Lower Inner Cover
Item
Part No.
Description
Remark
Spare
parts
1
32-0250003-10LF
GROUND PLATE FOR PLATEN
2
32-0250004-00LF
GROUND PLATE FOR PEELER BAR
3
37-1403006-34LF
SCREW / TP3*6 (connect ground plate for
platen, ground plate for peeler bar, M3
ground wire(L155mm) & lower inner cover)
2 pcs
4
36-0250002-10LF
PLASTIC LAMINATE (BLACK)
5
37-1403006-74LF
SCREW + WASHER / TP3*6 (For Plastic
laminate & lower inner cover)
4 pcs
6
37-1402608-31LF
37-1402608-34LF
SCREW / TP 2.6 * 8 (For Label guide rack
fixing plate & lower inner cover)
2 pcs
7
30-0250014-00LF
LABEL GUIDE RACK (RIGHT) SENSOR
COVER
8
37-1401706-24LF
SCREW TP1.7*6 (For Label guide rack /
right & Gap sensor (Receiver) PCB ASS’Y &
Label guide rack (right) sensor cover)
2 pcs
9
30-0250012-00LF
LABEL GUIDE RACK (RIGHT)
10
30-0250013-00LF
LABEL GUIDE RACK (LEFT)
11
98-0250023-10LF
GAP SENSOR (TRANSMITTER) PCB
ASS’Y
1%
12
37-1401704-14LF
SCREW / TP1.7*4 (For label guide rack
(right) & gap sensor (transmitter) PCB
ASS’Y x 2 pcs, For black mark sensor
ASS’Y & black mark sensor fixing plate &
lower inner cover x 1pc
3 pcs
13
98-0250024-10LF
GAP SENSOR (RECEIVER) PCB ASS’Y
1%
14
30-0130034-00LF
SPUR GEAR / 10T
1%
15
30-0250025-40LF
LABEL GUIDE RACK FIXING PLATE
16
32-0500005-00LF
BLACK MARK SENSOR FIXING PLATE
17
98-0250021-00LF
BLACK MARK SENSOR ASS’Y
18
98-0250022-00LF
STEPPING MOTOR ASS’Y (Including
stepping motor)
19
37-1403008-34LF
SCREW / TP3*8 (For stepping motor ASS’Y
& lower inner cover)
8 pcs

TSC TTP-245 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm (4.25")
Max Print Speed	5 inches per second
Interface	Parallel
Ribbon Capacity	300 meters
Label Width	1 to 4.4 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Print Length	39.37 inches (1000 mm)
Label Thickness	0.08 to 0.2 mm
