TSC TTP-245 - Lower Inner Cover

TTP-245 / TTP-343
94
9.5.1 Lower Inner Cover
Item
Part No.
Description
Remark
Spare
parts
1
30-0250003-70
98-0250161-00LF
LOWER INNER COVER ASSY includes
30-0250003-80LF Lower inner cover*1
36-0250016-00LF Top cover operation name plate *1
36-0130043-00LF Cable tie*2
36-0500014-00LF Adhesive backed mount*2
36-0250008-00LF Transparent plastic sensor cover *1
36-0250023-00LF Rubber plug*1
37-1402606-34LF Screw*1
1 set (for
RMA)
1%
2
32-0250028-00LF
PEELER BAR(20 degree)
3
98-0250115-00LF
PLATEN ASS’Y (TTP-245/Gray)
2%
98-0500009-00LF
PLATEN ASS’Y (TTP-343/Black)
4
37-1401705-14LF
SCREW / TP1.7*5 (To fix the rear paper guide
& fixing plate & lower inner cover)
2 pcs.
5
30-0500024-00LF
REAR PAPER GUIDE
2 pcs.
6
32-0500015-00LF
REAR PAPER GUIDE FIXING PLATE
2 pcs.
7
30-0250009-20LF
HINGE HOLDER
8
30-0250010-20LF
HINGE HOLDER
9
37-1402608-31LF
37-1402608-34LF
SCREW / TP 2.6 * 8 (For lower inner cover &
the hinge holders)
6 pcs.
10
30-0250021-00LF
TEFLON TUBE
11
32-0250014-00LF
TEFLON TUBE SHAFT
12
37-1403008-34LF
SCREW TP3*8 (For Teflon tube shaft & lower
inner cover)
2 pcs
13
36-0250008-00LF
DUST PREVENTION PLATE
(L75.6*W12.6*T0.3) FOR GAP SENSOR
14
98-0250066-00LF
TOP COVER SUPPORT DAMPER MODULE
ASS'Y
1%
15
37-1403015-32LF
SCREW 3*15 BLACK (For top cover damper
module Ass’y)
1 pc
16
37-1403008-34LF
SCREW TP3*8 (For top cover damper module
Ass’y)
3 pcs
