3.4. Replacing Main Board
1. Please refer to 3.3 for disassembling the LOWER COVER and LOWER inner
cover.
2. Disconnect all harnesses.
3. Remove 4 screws on the main board.
4. Replace the main board/lower inner cover.
5. Reassemble parts in reverse procedures.
