TSC TTP-245

TTP-245 / TTP-343
98
9.6 Stepping Motor Assembly
Item
Part No.
Description
Remark
Spare
parts
1
98-0250022-00LF
STEPPING MOTOR ASS’Y for 203 DPI
(Including stepping motor)
2
98-0270001-00LF
STEPPING MOTOR ASS’Y for 300 DPI
(Including stepping motor)
3
65-0030006-00LF
STEPPING MOTOR WITH 15 GEAR (For
203 DPI)
1%
4
65-0010010-00LF
STEPPING MOTOR WITH 15 GEAR (For
300 DPI)
1%
5
32-0250006-10LF
STEPPING MOTOR BRACKET / METAL
(For 203 DPI)
6
32-0270001-00LF
STEPPING MOTOR BRACKET / METAL
(For 300 DPI )
7
30-0500014-10LF
SPUR GEAR / 16T-48T
1 pcs.
8
30-0500013-10LF
SPUR GEAR / 44T
1 pcs.
9
30-0270001-00LF
SPUR GEAR 20T / 30T (For 300 DPI
only)
1 pcs
10
32-0500019-00LF
GEAR SHAFT
2 pcs (for
203 DPI)
3 pcs (for
300 DPI.
11
37-1503006-G4LF
SCREW M3*6 (For Stepping motor
bracket & gear cover)
5 pcs
12
32-0500009-10LF
TORSION SPRING
13
32-0500008-10LF
TORSION SPRING
14
37-3450110-04LF
E- RING / 5mm (inside shaft for hook)
2 pcs.
15
37-3440090-04LF
E- RING / 4mm (outside shaft for hook)
2 pcs.
16
37-1503006-74LF
SCREW + WASHER / M3*6
(To fix stepping motor bracket & stepping
motor)
2 pcs.
17
32-0250009-10LF
SHAFT FOR TOP COVER OPEN LEVER
18
30-0250030-30LF
TOP COVER OPEN LEVER
1%
19
30-0250029-30LF
TOP COVER OPEN LEVER
1%
20
30-0250017-10LF
GEAR COVER
21
30-0250011-10LF
TOP COVER OPEN LEVER FIXTURE
