TSC TTP-245 Service Manual

TTP-245 / TTP-343
85
9. PARTS LIST
9.1 Cover
Item
Part No.
Description
Remark
Spare
parts
1
98-0250029-10LF
98-0250166-00LF
TOP COVER ASS’Y includes:
30-0250002-30LF*1 TOP COVER
30-0250005-20LF*1 CLEAR TOP COVER
36-0250009-00LF*2 PROTECTIVE FILM (FOR CLEAR TOP COVER)
30-0250007-10LF*1 CLEAR WINDOW
36-0250005-00LF*1 PROTECTIVE FILM (FOR CLEAR WINDOW)
30-0250006-30LF*1 FEED BUTTON
36-0250003-00LF*2 LATCH FOR RIBBON ACCESS WINDOW
1set
(for
RMA)
2
30-0250001-30LF
LOWER COVER
3
30-0250008-30LF
MEMORY CARD COVER
4
37-1403020-31LF
37-1403020-34LF
SCREW / TP 3 * 20 (For memory card cover)
1 pc.
5
37-1402608-31LF
37-1402608-34LF
SCREW / TP2.6*8 (For lower cover & hinge holders)
2 pcs.
6
37-1403010-34LF
SCREW TP3*10 (For lower cover to fix lower inner
cover front side)
4 pcs
7
37-1403024-34LF
SCREW TP3*24 (For lower cover to fix lower inner
cover rear side)
2 pcs
8
98-0250013-00
98-0250013-10LF
FEED BUTTON ASS’Y
9
37-1403006-34LF
SCREW TP3*6 (For feed button)
2 pcs
10
36-0250003-00LF
LATCH FOR RIBBON ACCESS WINDOW
2 pcs
2%
11
37-1403020-31LF
37-1403020-34LF
SCREW / TP3*20 (For top cover & top inner cover)
6 pcs
12
30-0250026-30LF
FRONT PANEL (standard)
13
98-0250123-20LF
MAIN BOARD ASS’Y
5%
98-0250123-24LF
MAIN BOARD ASS’Y
(Main Board + RTC)
Factory
Option

TSC TTP-245 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm (4.25")
Max Print Speed	5 inches per second
Interface	Parallel
Ribbon Capacity	300 meters
Label Width	1 to 4.4 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Print Length	39.37 inches (1000 mm)
Label Thickness	0.08 to 0.2 mm
