TSC TTP-245 Service Manual

TTP-245 / TTP-343
19
2.6. Memory Map
FFFF FFFF
ON-CHIP RAM
FFFF F000
RESERVED
FFFF 8800
FFFF 87FF
REGISTER
FFFF 81A0
FFFF 8000
RESERVED
00FF FFFF
.
.
0200 0000
.
DRAM SPACE
.
0100 0000
00E0 0000
TPH STB
I/O
00D8 0003
Motor Phase2
00D8 0002
Motor Phase1
00D8 0001
RTC register data
00C0 0000
00D8 0000
RTC register address
Memory Card
00D0 0003
ECP
00D0 0002
Ribbon Sensor value
00D0 0001
Black mark sensor value
0080 0000
00D0 0000
Gap sensor Value
Memory Card
00C8 0003
Buzzer
00C8 0002
Reserved

TSC TTP-245 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm (4.25")
Max Print Speed	5 inches per second
Interface	Parallel
Ribbon Capacity	300 meters
Label Width	1 to 4.4 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Print Length	39.37 inches (1000 mm)
Label Thickness	0.08 to 0.2 mm
