TSC TTP-245 - Top Inner Cover

TTP-245 / TTP-343
89
9.3 Top Inner Cover
Item
Part No.
Description
Remark
Spare
parts
1
30-0250004-80
98-0250118-00LF
TOP INNER COVER ASSY includes
30-0250004-90LF Top inner cover*1
30-0250004-A0LF
30-0250023-90LF Top cover support*1
37-1503012-34LF Screw for top inner cover*1
37-4000030-04LF Nut for top cover support*1
32-0250013-00LF Tph ground plate*1
37-1403006-34LF Screw for tph ground plate*1
36-0250012-00LF Media loading instruction label *1
36-0500011-00LF High temp.warning label *2
36-0250010-10LF Non-reflective label*1
36-0500014-00LF Adhesive backed mount*3
36-0500015-00 Cable tie*2
36-0130043-00LF
1 set (for
RMA)
3%
2
98-0250019-00
98-0250019-10LF
HEAD OPEN MICRO SWITCH ASS'Y
1%
3
32-0500021-00LF
HEAD OPEN MICRO SWITCH FIXING
PLATE
4
70-52B2604-10LF
PRINT HEAD HARNESS
1 pcs
5
98-0250128-00LF
TPH MODULE ASS’Y for 203 DPI
3%
98-0270032-00LF
TPH MODULE ASS’Y for 300 DPI
3%
6
32-0250013-00LF
GROUND PLATE FOR TPH
7
37-1403020-31LF
37-1403020-34LF
SCREW / TP3*20 (For Top cover & top inner
cover)
6 pcs
8
30-0250023-90LF
TOP COVER SUPPORT
9
37-4000030-04LF
NUT / M3 (For top cover support & top inner
cover)
1 pcs
10
37-1503012-34LF
SCREW / M3*12 (For top cover support &
top inner cover)
1 pcs
11
98-0250020-10LF
RIBBON END SENSOR PCB ASS’Y
1%
12
37-1402005-34LF
SCREW / TP2*5 (For Ribbon end sensor
PCB ASS’Y & top inner cover)
2 pcs
13
37-1403006-34LF
SCREW / TP3*6 (For head open micro
switch fixing plate & head open micro switch
2 pcs
