TTP-245 / TTP-343
46
3.5. Replacing Platen Assembly
1. Squeeze two sides of platen assembly and take it out.
2. Replace a platen.
3. Reassemble it in reverse procedures.
Squeeze Here
Platen
Squeeze Here
