TSC TTP-245 Service Manual

TTP-245 / TTP-343
87
9.2 Main Board
Item
Part No.
Description
Remark
Spare
parts
1
98-0250123-20LF
MAIN BOARD ASS’Y
5%
98-0250123-24LF
MAIN BOARD ASS’Y
(Main Board + RTC)
Factory
Option
2
80-PBL3717-00LF
DRIVER IC (For stepping motor)
U11,U12,
2%
3
80-PBL3717-00LF
DRIVER IC (For DC motor)
U13
1%
4
80-UDN3952-00
CUTTER DRIVER IC A3952SB (Non-RoHS)
U14
Option
2%
80-A3953SB-00LF
CUTTER DRIVER IC A3953SB (RoHS)
5
98-0500026-10LF
2MB MEMORY CARD
Option
98-0500028-10LF
4MB MEMORY CARD
Option
98-0500029-10LF
6MB MEMORY CARD
Option
98-0500030-10LF
8MB MEMORY CARD
Option
6
63-04PSS01-00LF
POWER SWITCH
7
37-1503008-74LF
SCREW / M3*8 + WASHER (For Main board
& ground wire)
1 pc
8
37-1403006-34LF
SCREW / TP3*6 (For Main board & lower
cover)
3 pcs

TSC TTP-245 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm (4.25")
Max Print Speed	5 inches per second
Interface	Parallel
Ribbon Capacity	300 meters
Label Width	1 to 4.4 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Print Length	39.37 inches (1000 mm)
Label Thickness	0.08 to 0.2 mm
