TSC TTP-245 Service Manual

TTP-245 / TTP-343
7
1.3. Supply Specification
1.3.1. Paper
Item
Specification
Type
Label (Continuous , Die-cut , Fan-fold).
Wound Type
Outside wound.
Width
20~112mm (0.78" ~ 4.4")
Length
( for peel and cutter )
10mm ~ 1000mm (0.4” ~ 39”).
25.4mm ~ 1000mm (1” ~ 39”).
Thickness
0.06mm ~ 0.19mm.
Roll Diameter
5”.
Roll Core Diameter
25.4mm ~ 76.2mm (1” ~ 3”).
Gap Height
2mm min.
Black Mark Height
2mm min.
Black Mark Width
8mm min.
1.3.2. Ribbon
Item
Specification
Type
Wax, Wax / Resin, Resin.
Core Diameter
1".
Width
Max 110mm.
Capacity
300m with 1" core.
Wound Type
Outside wound.
Ribbon End
Clear or silver end tape.

TSC TTP-245 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm (4.25")
Max Print Speed	5 inches per second
Interface	Parallel
Ribbon Capacity	300 meters
Label Width	1 to 4.4 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Print Length	39.37 inches (1000 mm)
Label Thickness	0.08 to 0.2 mm
