TSC TTP-245

TTP-245 / TTP-343
6
Force Gap Sensor
Calibration
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns red/amber after 5
green/amber blinks. (Any red/amber will do during the 5
blinks).
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks) 
green (5 blinks)  green/amber (5 blinks) 
red/amber (5 blinks)  solid green
Skip AUTO.BAS
1. Turn off printer power.
2. Press the FEED button and then turn on power.
3. Release the FEED button when LED becomes solid
green.
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks) 
green (5 blinks)  green/amber (5 blinks) 
red/amber (5 blinks)  solid green
4. Printer will be interrupted to run the AUTO.BAS program.
