TSC TTP-245 Service Manual

TTP-245 / TTP-343
101
98-0250042-00
98-0250131-00LF
PARTIAL CUT CUTTER ASS’Y
(includes motor driver IC)
Option
14
98-1000004-00
98-1000011-00LF
EXTERNAL WIRELESS PRINT SERVER /US
Option
98-1000005-00
98-1000012-00LF
EXTERNAL WIRELESS PRINT SERVER /EU
15
98-0500032-00LF
REAL TIME CLOCK ASS'Y
Factory
option
16
98-0500026-10LF
2MB MEMORY CARD
Option
98-0500028-10LF
4MB MEMORY CARD
Option
98-0500029-10LF
6MB MEMORY CARD
Option
98-0500030-10LF
8MB MEMORY CARD
Option
17
98-0250134-00LF
INTERNAL PRINT SERVER ASS’Y (T)
Option
98-0250135-00LF
INTERNAL PRINT SERVER ASS’Y (C)
Option
98-0250136-00LF
INTERNAL WIRELESS PRINT SERVER
ASS’Y (C)
Option
18
49-OKPE156-20LF
BUZZER
Factory
option

TSC TTP-245 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm (4.25")
Max Print Speed	5 inches per second
Interface	Parallel
Ribbon Capacity	300 meters
Label Width	1 to 4.4 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Print Length	39.37 inches (1000 mm)
Label Thickness	0.08 to 0.2 mm
