TSC TTP-245 Service Manual

TTP-245 / TTP-343
3
Enclosure
Structure
Dimension
Operation Panel
Double-walled plastic.
Standard Model: 314mm(L) x 213mm(W) x 188mm(H)
One push switch, and one indicator LED (Green,
Orange, Red colors).
Hardware
Sensor
Transmissive sensor (offset 6 mm from liner
edge).
Reflective sensor (position adjustable).
Head open micro switch.
Ribbon end sensor
Memory
2M byte Flash memory
2M bytes DRAM
Interface
RS-232C (max baud rate, 19,200 bps).
USB: V1.1.
Centronics.
Power
AC input: 100-240V universal auto switching power
supply.
DC output: 24V 3.75A.
Firmware
Font Type
8 alpha-numeric bitmap fonts, and 1 true type font.
Rotation
0, 90,180 and 270 degrees.
Barcode Format
1D Bar code
Code 39, Code 93, Code 128UCC, Code128 subsets
A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13,
EAN-128, UPC-A, UPC-E, EAN and UPC2(5) digits
add-on, MSI, PLESSEY, POSTNET, ChinaPOST,
ITF-14, EAN-14.
2D Bar code
PDF-417, Maxicode, and DataMatrix, QR CODE.
Command Set
TSPL2
Environment
Operation
Temperature: 5℃ ~ 40℃.
Relative Humidity: 25% ~ 85% (Non Condensing).
Storage
Temperature: -40℃ ~ 60℃.
Relative Humidity: 10% ~ 90% (Non Condensing).

TSC TTP-245 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm (4.25")
Max Print Speed	5 inches per second
Interface	Parallel
Ribbon Capacity	300 meters
Label Width	1 to 4.4 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Print Length	39.37 inches (1000 mm)
Label Thickness	0.08 to 0.2 mm
