Utax CD 1020 - Page 274

2AV/X
2-3-9
Terminals (CN) Voltage Remarks
2-3
1-2 1-1 3.3 V DC 3.3 V DC supply from PSPCB, input
1-5, 6 1-3, 4 5 V DC 5 V DC supply from PSPCB, input
1-9, 10 1-7, 8 24 V DC 24 V DC supply from PSPCB, input
3-1 3-2 12 V DC 12 V DC supply from PSPCB, input
3-3 1-3 0/5 V DC FH on/off, output
3-4 1-7 0/24 V DC MSW on/off, input
3-5 1-7 24 V DC 24 V DC supply for MSW, output
3-6 3-8 5 V DC 5 V DC supply for RSW, output
3-7 3-8 0/5 V DC RSW on/off, input
3-10 3-9 0/5 V DC PSW-U on/off, input
3-11 3-9 5 V DC 5 V DC supply for PSW-U, output
4-1 4-2 24 V DC 24 V DC supply for HVTPCB, output
4-3 4-2 0/5 V DC Main charging on/off, output
4-4 4-2 0/5 V DC Developing bias on/off, output
4-5 4-2 0/5 V DC Transfer charging on/off, output
4-6 4-2 0 - 5 V DC GRID control voltage, output
4-7 4-2 0 - 5 V DC Developing bias control voltage, output
4-8 4-2 0 - 5 V DC Transfer charging control voltage, output
4-9 4-2 0/5 V DC Main charging ALM signal, input
4-10 4-2 0/24 V DC RCL on/off, output
4-11 4-2 24 V DC 24 V DC supply for RCL, output
4-12 4-2 0/24 V DC BYPPFCL on/off, output
4-13 4-2 24 V DC 24 V DC supply for BYPPFCL, output
4-14 4-2 0/24 V DC PFCL-U on/off, output
4-15 4-2 24 V DC 24 V DC supply for PFCL-U, output
5-1 5-2 0/5 V DC Duplex unit*
4
detection signal, input
5-3 5-2 0/24 V DC FSSOL*
4
latch-on signal, output
5-4 5-2 0/24 V DC FSSOL*
4
actuate signal, output
5-5 5-2 24 V DC 24 V DC supply for FSSOL*
4
, output
5-7 5-6 0/5 V DC DUPPCSW2*
4
on/off, input
5-8 5-6 5 V DC 5 V DC supply for DUPPCSW2*
4
, output
5-10 5-9 0/5 V DC DUPPCSW1*
4
on/off, input
5-11 5-9 5 V DC 5 V DC supply for DUPPCSW1*
4
, output
6-1 6-3 5 V DC 5 V DC supply for BYPPSW*
1
, output
6-2 6-3 0/5 V DC BYPPSW*
1
on/off, input
6-4 6-7 0/5 V DC BYPPWSW width detection signal, input
6-5 6-7 0/5 V DC BYPPWSW width detection signal, input
6-6 6-7 0/5 V DC BYPPWSW width detection signal, input
7-1 7-2 ETTH detection voltage, input
7-3 7-2 HUMSENS detection voltage, input
7-4 7-2 5 V DC 5 V DC supply for HUMSENS, output
8-1 8-22 24 V DC 24 V DC supply for lower drawer*
2
, optional drawer*
3
, output
8-2 8-22 24 V DC 24 V DC supply for lower drawer*
2
, optional drawer*
3
, output
8-3 8-22 0/24 V DC PFCL-L*
2
on/off, output
8-4 8-22 0/24 V DC PFCL (ST) 1*
3
on/off, output
8-5 8-22 0/24 V DC PFCL (ST) 2*
3
on/off, output
8-6 8-22 5/0 V DC (pulse) SSW3*
2
scan signal, output (SCAN1)
8-7 8-22 5/0 V DC (pulse) SSW3*
2
scan signal, output (SCAN2)
8-8 8-22 5/0 V DC (pulse) SSW3*
2
scan signal, output (SCAN3)
8-9 8-22 5/0 V DC (pulse) SSW3*
2
return signal, input (SENS0)
8-10 8-22 5/0 V DC (pulse) SSW3*
2
return signal, input (SENS1)
8-11 8-22 5/0 V DC (pulse) SSW3*
2
return signal, input (SENS2)
8-12 8-22 5/0 V DC (pulse) SSW3*
2
return signal, input (SENS3)
8-13 8-22 5/0 V DC (pulse) SSW3*
2
return signal, input (SENS4)
8-14 8-22 5/0 V DC (pulse) SSW3*
2
return signal, input (SENS5)
*1: For 20 cpm copier only. *2: Standard for 20 cpm copier/optional for 15 cpm copier.
*3: Optional for both 20 cpm and 15 cpm copiers. *4: Optional for 20 cpm copier only.
