Utax CD 1020 - Page 275

2AV/X
2-3-10
Terminals (CN) Voltage Remarks
2-3
8-15 8-22 0/5 V DC PSW-L*
2
on/off, input
8-16 8-22 0/5 V DC PSW (ST) 1*
3
on/off, input
8-17 8-22 0/5 V DC PSW (ST) 2*
3
on/off, input
8-18 8-22 0/24 V DC DDM*2 on/off, output
8-19 8-22 0/24 V DC DDM (ST) 1*
3
on/off, output
8-20 8-22 0/24 V DC DDM (ST) 2*
3
on/off, output
8-21 8-22 5 V DC 5 V DC supply for lower drawer*
2
, optional drawer*
3
, output
8-23 8-22 0/5 V DC DFSW*
2
on/off, input
8-24 8-22 0/5 V DC DFSW (ST) 1*
3
on/off, input
8-25 8-22 0/5 V DC DFSW (ST) 2*
3
on/off, input
8-26 8-22 0/5 V DC (pulse) DDM drive clock pulse, output
9-2 9-1 0/5 V DC PSSW1-U on/off, input
9-4 9-3 0/5 V DC PSSW2-U on/off, input
9-6 9-5 0/5 V DC PSSW3-U on/off, input
9-8 9-7 0/5 V DC PSSW4-U on/off, input
10-1 10-4 24 V DC 24 V DC supply for key card*
3
, key counter*
3
, output
10-3 10-4 0/24 V DC SSW1 on/off, input
10-5 10-4 0/5 V DC Key card*
3
, key counter*
3
copy count signal, output
10-6 10-4 0/5 V DC Key card*
3
, key counter*
3
connection signal, input
10-7 10-4 24 V DC SSW2 on/off, output
11-1 10-4 24/14 V DC TFM drive control signal (+), output
11-2 10-4 14/24 V DC TFM drive control signal (-), output
11-3 10-4 24 V DC 24 V DC supply for CFM1, output
11-4 10-4 12/24 V DC CFM1 half speed/full speed, output
11-5 10-4 0/24 V DC CFM1 on/off, output
11-6 10-4 24 V DC 24 V DC supply for CFM2, output
11-7 10-4 12/24 V DC CFM2 half speed/full speed, output
11-8 10-4 0/24 V DC CFM2 on/off, output
11-9 10-4 24 V DC 24 V DC supply for CFM3, output
11-10 10-4 12/24 V DC CFM3 half speed/full speed, output
11-11 10-4 0/24 V DC CFM3 on/off, output
12-1 12-12 24 V DC 24 V DC supply for CL, output
12-2 12-12 0/24 V DC CL on/off, output
12-3 12-12 24 V DC 24 V DC supply for total counter, output
12-4 12-12 0/24 V DC Total counter on/off, input
12-6 12-5 0/5 V DC ESW on/off, input
12-7 12-5 5 V DC 5 V DC supply for ESW, output
12-8 12-5 0 - 5 V DC FTH detection voltage, input
12-9 12-5 5 V DC 5 V DC supply for FTH, output
12-10 12-12 24 V DC 24 V DC supply for DM, output
12-11 12-12 24 V DC 24 V DC supply for DM, output
12-14 12-12 5 V DC 5 V DC supply for DM, output
12-16 12-12 0/5 V DC DM on/off, output
12-17 12-12 0/5 V DC (pulse) DM drive clock pulse, output
12-18 12-12 0/5 V DC DM LOCK signal, input
13-1 13-4 24 V DC 24 V DC supply for TNS, output
13-2 13-4 TNS detection voltage, input
13-3 13-4 0 - 15 V DC TNS control voltage, output
13-5 13-6 0/5 V DC Connection detection signal, input
13-7 13-8 0/5 V DC WTDSW on/off, input
14-6A 14-4A 5 V DC 5 V DC supply for STDF*
3
, SRDF*
4
, output
14-7A 14-4A 5 V DC 5 V DC supply for STDF*
3
, SRDF*
4
, output
14-10A 14-8A 24 V DC 24 V DC supply for STDF*
3
, SRDF*
4
, output
14-10A 14-8A 24 V DC 24 V DC supply for STDF*
3
, SRDF*
4
, output
14-1B 14-4A 0/5 V DC OSLED*
4
(red) on/off, output
*1: For 20 cpm copier only. *2: Standard for 20 cpm copier/optional for 15 cpm copier.
*3: Optional for both 20 cpm and 15 cpm copiers. *4: Optional for 20 cpm copier only.
