Terminals (CN) Voltage Remarks
2-3
14-2B 14-4A 0/5 V DC OSLED*
4
(green) on/off, output
14-3B 14-4A 0/5 V DC SBPSOL*
4
release signal, output
14-4B 14-4A 0/5 V DC SBPSOL*
4
actuate signal, output
14-5B 14-4A 0/5 V DC OFCL*
4
on/off, output
14-6B 14-4A 0/5 V DC EFSSOL*
4
on/off, output
14-8B 14-4A 0/5 V DC SBFSSOL*
4
on/off, output
14-9B 14-4A 0/5 V DC OFSOL*
4
release signal, output
14-10B 14-4A 0/5 V DC OFSOL*
4
actuate signal, output
14-11B 14-4A 0/5 V DC OFM*
4
ENABLE signal, output
15-1A 14-4 0/5 V DC OFM*
3
ENABLE signal, output
15-2A 14-4 0/5 V DC OSDPCB*
3
, OSBSW*
4
on/off, input
15-3A 14-4 0/5 V DC OSDPCB*
3
, OFSW*
4
on/off, input
15-4A 14-4 0/5 V DC OSDPCB*
3
, OSSW*
4
on/off, input
15-5A 14-4 0/5 V DC OSDPCB*
3
on/off, input
15-6A 14-4 0/5 V DC OSDPCB*
3
on/off, input
15-7A 14-4 0/5 V DC STDF*
3
, SRDF*
4
installed/not installed signal, input
15-8A 14-4 0/5 V DC OSWSW*
4
on/off, input
15-9A 14-4 0/5 V DC DFSSW2*
3
on/off, input
15-10A 14-4 0/5 V DC DFSSW1*
3
on/off, input
15-11A 14-4 0/5 V DC OSDPCB*
3
, OSLSW*
4
on/off, input
15-12A 14-4 0/5 V DC DFTSW*
3
on/off, input
15-2B 14-4 0/5 V DC OFM*
3
control signal OFM RET, output
15-3B 14-4 0/5 V DC (pulse) OFM*
3
drive clock pulse, output
15-4B 14-4 0/5 V DC OFM*
3
rotational direction switching signal OFM CWB, output
15-5B 14-4 0/5 V DC OCM*
3
ENABLE signal, output
15-6B 14-4 0/5 V DC OCM*
3
control signal OCM RET, output
15-7B 14-4 0/5 V DC (pulse) OCM*
3
drive clock pulse, output
15-8B 14-4 0/5 V DC OCM*
3
rotational direction switching signal OCM CWB, output
15-9B 14-4 OCM*
3
current control voltage OCM Vref, output
15-10B 14-4 0/5 V DC OCM*
3
drive control signal OCM M3, output
15-11B 14-4 0/5 V DC OCM*
3
drive control signal OCM M2, output
15-12B 14-4 0/5 V DC OCM*
3
drive control signal OCM M1, output
16-1 16-2 0/5 V DC Job separator*
3
, duplex unit*
4
connection signal, input
16-3 16-2 24 V DC 24 V DC supply for FSSOL*
3
, output
16-4 16-2 0/24 V DC FSSOL*
3
actuate signal, output
16-5 16-2 24/0 V DC FSSOL*
3
release signal, output
16-6 16-8 5 V DC 5 V DC supply for JBESW*
3
, output
16-7 16-8 0/5 V DC JBESW*
3
on/off, input
16-10 16-2 24/0 V DC SBSOL*
4
actuate signal, output
16-11 16-2 24/0 V DC SBSOL*
4
release signal, output
16-13 16-12 0/5 V DC JOFSW*
3
on/off, input
16-14 16-12 5 V DC 5 V DC supply for JOFSW*
3
, output
16-15 16-12 5 V DC 5 V DC supply for LED*
3
, output
16-16 16-12 0/5 V DC LED*
3
on/off, output
18-1 18-2 24 V DC 24 V DC supply for MDPCB*
4
, output
18-3 18-4 5 V DC 5 V DC supply for MDPCB*
4
, output
18-5 18-4 0/5 V DC (pulse) FSM*
4
drive clock pulse, output
18-6 18-4 0/5 V DC FSM*
4
R/L signal, output
18-7 18-4 0/5 V DC FSM*
4
on/off, output
18-8 18-4 24 V DC 24 V DC supply for DUPOCSW*
4
, output
18-9 18-4 0/5 V DC FSM*
4
MODE signal, output
18-10 18-4 24 V DC DUPOCSW*
4
on/off, output
18-11 18-4 0/5 V DC MACHINE TYPE signal, input
20-1 20-2 24 V DC 24 V DC supply for PM, output
20-3 20-2 0/5 V DC PM S/S signal, output
