2AV/X
2-3-12
Terminals (CN) Voltage Remarks
2-3
20-4 20-2 0/5 V DC PM READY signal, input
20-5 20-2 0/5 V DC (pulse) PM drive clock pulse, output
21-1 21-2 0/5 V DC LDPCB HSYNC signal, input
21-3 21-2 5 V DC 5 V DC supply for LDPCB, output
21-5 21-2 0/5 V DC LDPCB ENABLE signal, output
21-6 21-2 0/5 V DC LDPCB VIDEO signal, output
21-7 21-2 0/5 V DC LDPCB S/H signal, output
22-2 22-1 0/5 V DC CCDPCB SHIFT signal, output
22-4 22-3 0/5 V DC CCDPCB CLP signal, output
22-6 22-5 0/5 V DC CCDPCB RESET signal, output
22-8 22-7 0/5 V DC (pulse) CCDPCB clock pulse, output
22-10 22-9 0/5 V DC (pulse) CCDPCB clock pulse, output
23-2 23-1 12 V DC 12 V DC supply for CCDPCB, output
23-4 23-3 0/5 V DC CCDPCB image signal (EVEN), input
23-6 23-5 0/5 V DC CCDPCB image signal (ODD), input
24-1 24-5 0/5 V DC EL on/off, output
24-2 24-5 0/5 V DC EL on/off, output
24-3 24-5 24 V DC 24 V DC supply for INPCB, output
24-4 24-5 24 V DC 24 V DC supply for INPCB, output
25-2 25-1 0/5 V DC ODSW on/off, input
25-3 25-1 5 V DC 5 V DC supply for ODSW, output
25-5 25-4 0/5 V DC SHPSW on/off, input
25-6 25-4 5 V DC 5 V DC supply for SHPSW, output
25-8 25-7 0/5 V DC 5 V DC supply for OSDS, output
25-9 25-7 5 V DC OSDS on/off, input
26-1 27-12 0/5 V DC OPCB KEY0 signal, input
26-2 27-12 0/5 V DC OPCB KEY1 signal, input
26-3 27-12 0/5 V DC OPCB KEY2 signal, input
26-4 27-12 0/5 V DC OPCB KEY3 signal, input
26-5 27-12 0/5 V DC OPCB KEY4 signal, input
26-6 27-12 0/5 V DC OPCB KEY5 signal, input
26-7 27-12 0/5 V DC OPCB KEY6 signal, input
26-8 27-12 0/5 V DC OPCB KEY7 signal, input
26-9 27-12 0/5 V DC OPCB LEDON0 signal, output
26-10 27-12 0/5 V DC OPCB LEDON1 signal, output
26-11 27-12 0/5 V DC OPCB LEDON2 signal, output
26-13 27-12 0/5 V DC OPCB LEDON4 signal, output
26-14 27-12 0/5 V DC OPCB LEDON3 signal, output
26-15 27-12 0/5 V DC (pulse) OPCB SCAN7 signal, output
26-16 27-12 0/5 V DC (pulse) OPCB SCAN6 signal, output
26-17 27-12 0/5 V DC (pulse) OPCB SCAN5 signal, output
26-18 27-12 0/5 V DC (pulse) OPCB SCAN4 signal, output
26-19 27-12 0/5 V DC (pulse) OPCB SCAN3 signal, output
26-20 27-12 0/5 V DC (pulse) OPCB SCAN2 signal, output
26-21 27-12 0/5 V DC (pulse) OPCB SCAN1 signal, output
26-22 27-12 0/5 V DC (pulse) OPCB SCAN0 signal, output
27-1 27-12 0 - 5 V DC LCD Vdd signal, output
27-2 27-12 -12-0 V DC LCD Vee signal, output
27-3 27-12 0/5 V DC (pulse) LCD UD3 signal, output
27-4 27-12 0/5 V DC (pulse) LCD UD2 signal, output
27-5 27-12 0/5 V DC (pulse) LCD UD1 signal, output
27-6 27-12 0/5 V DC (pulse) LCD UD0 signal, output
27-7 27-12 0/5 V DC (pulse) LCD CP signal, output
27-8 27-12 0/5 V DC (pulse) LCD FLM signal, output
27-9 27-12 0/5 V DC LCD LEDENB signal, output
27-10 27-12 0/5 V DC (pulse) LCD LP signal, output
