2AV/X
2-3-13
Terminals (CN) Voltage Remarks
2-3
27-11 27-12 -12-0 V DC LCD Vo signal, output
28-1 24-5 0/24 V DC (pulse) SM coil energization pulse, output (_A)
28-2 24-5 24 V DC 24 V DC supply for SM, output
28-3 24-5 0/24 V DC (pulse) SM coil energization pulse, output (A)
28-4 24-5 0/24 V DC (pulse) SM coil energization pulse, output (B)
28-5 24-5 24 V DC 24 V DC supply for SM, output
28-6 24-5 0/24 V DC (pulse) SM coil energization pulse, output (_B)
32-1 10-4 24 V DC 24 V DC supply for SSW2, output
32-3 10-4 0/24 V DC SSW2 on/off, input
