Vacon 100 flow Installation Manual

Table 6: The options for MR10
Option Order code Location Description
The brake chopper
+DBIN
The options module Enables dynamic braking with an exter-
nal brake resistor.
The common mode filter +POCM The options module Decreases motor bearing currents.
The du/dt filter
+PODU
The options module Decreases motor bearing currents and
the stress on the motor insulation.
The external power con-
nection block
+PCTB
The cabinet Enables a more flexible connection of
motor cables. A loose option.
AC fuses and fuse switch +CIFD The options module Isolate the drive safely from the mains.
Flange mounting
+QFLG
- Enables mounting the drive through the
cabinet wall so that the control unit
stays inside the cabinet.
Installation kit for a
detached control unit ENC-QCDU
- An assembly plate and a 2 m cable to
install the control unit separated from
the power unit.
NOTE!
When your AC drive has the options module, more space is necessary for the
installation of the drive.
INSTALLATION INTO CABINET VACON · 33
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
5

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
