Vacon 100 flow Installation Manual

Table 11: The recommended mains cables and fuses in 208-240 V and 380-500 V
Enclosure
size
Type IL [A] Mains fuses per
phase (gG/gL) [A]
Mains and motor
cable (Cu/AI) [mm2]
Mains cable
terminal,
bolt size
[mm
2
]
Grounding
terminal,
bolt size
[mm
2
]
MR8
0140 2
0140 5
140 160
(3x70+35) (Cu)
(3x95+29) (Al)
M8 M8
0170 2
0170 5
170 200
(3x95+50) (Cu)
(3x150+41) (Al)
M8 M8
0205 2
0205 5
205 250
(3x120+70) (Cu)
(3x185+57) (Al)
M8 M8
MR9
0261 2
0261 5
261 315
(3x185+95) (Cu)
2x(3x120+41) (Al)
M10 M8
0310 2
0310 5
310 350
2x(3x95+50) (Cu)
2x(3x120+41) (Al)
M10 M8
MR10
0385 5 385 400
2x(3x120+70) (Cu)
2x(3x185+57) (Al)
M12 M8
0460 5 460 500
2x(3x185+95) (Cu)
2x(3x240+72) (Al)
M12 M8
0520 5 520 630
2x(3x185+95) (Cu)
3x(3x150+41) (Al)
M12 M8
0590 5 590 630
2x(3x240+120) (Cu)
3x(3x185+57) (Al)
M12 M8
MR12
0650 5 650 2 x 355
4x(3x95+50)
4x(3x120+41)
M12 M8
0730 5 730 2 x 400
4x(3x95+50)
4x(3x150+41)
M12 M8
0820 5 820 2 x 500
4x(3x120+70)
4x(3x185+57)
M12 M8
0920 5 920 2 x 500
4x(3x150+70)
4x(3x240+72)
M12 M8
1040 5 1040 2 x 630
4x(3x185+95)
6x(3x150+41)
M12 M8
1180 5 1180 2 x 630
4x(3x240+120)
6x(3x185+57)
M12 M8
VACON · 46 POWER CABLING
6
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
