Vacon 100 flow - Page 47

Table 12: The recommended mains cables and fuses in 525-690 V
Enclosure
size
Type IL [A] Mains fuses per
phase (gG/gL) [A]
Mains and motor
cable (Cu/AI) [mm2]
Mains cable
terminal,
bolt size
[mm
2
]
Grounding
terminal,
bolt size
[mm
2
]
MR8
0080 6
0080 7
80 100
3x35+16 (Cu)
3x50+21 (Al)
M8 M8
0100 6
0100 7
100 125
3x50+25 (Cu)
3x70+21 (Al)
M8 M8
0125 6
0125 7
125 160
3x70+35 (Cu)
3x95+29 (Al)
M8 M8
MR9
0144 6
0144 7
144 160
3x70+35 (Cu)
3x120+41 (Al)
M10 M8
0170 6
0170 7
170 200
3x95+50 (Cu)
3x150+41 (Al)
M10 M8
0208 6
0208 7
208 250
3x120+70 (Cu)
3x185+57 (Al)
M10 M8
MR10
0261 6
0261 7
261 315
3x185+95
2x(3x95+29)
M12 M8
0325 6
0325 7
325 355
3x240+120
2x(3x120+41)
M12 M8
0385 6
0385 7
385 400
2x(3x120+70)
2x(3x185+57)
M12 M8
0416 6
0416 7
416 450
2x(3x120+70)
2x(3x185+57)
M12 M8
MR12
0460 6
0460 7
460 2 x 315
2x(3x150+70)
2x(3x240+72)
M12 M8
0520 6
0520 7
520 2 x 315
2x(3x185+95)
4x(3x95+29)
M12 M8
0590 6
0590 7
590 2 x 315
4x(3x70+35)
4x(3x120+41)
M12 M8
0650 6
0650 7
650 2 x 355
4x(3x95+50)
4x(3x150+41)
M12 M8
0750 6
0750 7
750 2 x 400
4x(3x120+70)
4x(3x150+41)
M12 M8
0820 6
0820 7
820 2 x 425
4x(3x120+70)
4x(3x185+57)
M12 M8
