Vacon 100 flow Installation Manual

Table 13: Drive fuses, 208-240 V and 380-500 V, Mersen
Enclosure
size
Type I
L
[A] Catalogue number of the
fuse
Fuse
rating
[A]
Number
of fuses
needed
Fuse
size
Minimum
prospective
short
circuit
current
MR8
0140 2
0140 5
140 NH1UD69V250PV 250 3 1 1400
0170 2
0170 5
170 NH1UD69V350PV 350 3 1 2400
0205 2
0205 5
205 NH1UD69V400PV 400 3 1 2800
MR9
0261 2
0261 5
261 NH2UD69V500PV 500 3 2 3300
0310 2
0310 5
310 NH2UD69V630PV 630 3 2 5000
MR10
0385 5 385 NH2UD69V700PV 700 3 2 5700
0460 5 460 NH3UD69V900PV 900 3 3 7000
0520 5 520 NH3UD69V1000PV 1000 3 3 8600
0590 5 590 PC73UD90V10CPA 1000 3 3 13000
MR12
0650 5 650 NH2UD69V630PV 630 6 2 5000
0730 5 730 NH2UD69V700PV 700 6 2 5700
0820 5 820 NH3UD69V900PV 900 6 3 7000
0920 5 920 NH3UD69V1000PV 1000 6 3 8600
1040 5 1040 NH3UD69V1000PV 1000 6 3 8600
1180 5 1180 PC73UD90V10CPA 1000 6 3 13000
VACON · 48 POWER CABLING
6
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
