Vacon 100 flow Installation Manual

Table 14: Drive fuses, 525-690 V, Mersen
Enclosure
size
Type I
L
[A] Catalogue number of the
fuse
Fuse
rating
[A]
Number
of fuses
needed
Fuse
size
Minimum
prospective
short
circuit
current
MR8
0080 6
0080 7
80 NH1UD69V125PV 125 3 1 500
0100 6
0100 7
100 NH1UD69V160PV 160 3 1 700
0125 6
0125 7
125 NH1UD69V200PV 200 3 1 1000
MR9
0144 6
0144 7
144 NH1UD69V315PV 315 3 1 2000
0170 6
0170 7
170 NH1UD69V350PV 350 3 1 2400
0208 6
0208 7
208 NH1UD69V400PV 400 3 1 2800
MR10
0261 6
0261 7
261 NH2UD69V400PV 400 3 2 2800
0325 6
0325 7
325 NH2UD69V500PV 500 3 2 3300
0385 6
0385 7
385 NH2UD69V630PV 630 3 2 5000
0416 6
0416 7
416 NH3UD69V900PV 900 3 3 7100
MR12
0460 6
0460 7
460 NH2UD69V400PV 400 6 2 2400
0520 6
0520 7
520 NH2UD69V450PV 450 6 2 2800
0590 6
0590 7
590 NH2UD69V500PV 500 6 2 3300
0650 6
0650 7
650 NH2UD69V550PV 550 6 3 4000
0750 6
0750 7
750 NH2UD69V630PV 630 6 2 5000
0820 6
0820 7
820 NH3UD69V900PV 900 6 3 7100
POWER CABLING VACON · 49
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
6

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
