Vacon 100 flow Installation Manual

Table 17: The cable and fuse sizes for VACON
®
100 INDUSTRIAL and FLOW in North America,
mains voltage 208-240 V and 380-500 V
Enclosure
size
Type IL [A] Fuse
(Class T/J)
[A]
Mains and
motor cable
(Cu) [AWG/
kcmil]
Terminal cable size
Mains cable
terminal [AWG/
kcmil]
Grounding
terminal [AWG/
kcmil]
MR8
0140 2
0140 5
140.0 200 3/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0170 2
0170 5
170.0 225 250 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil
0205 2
0205 5
205.0 250 350 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil
MR9
0261 2
0261 5
261.0 350 2x250 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil
0310 2
0310 5
310.0 400 2x350 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil
MR10
0385 5 385 500 2x250 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil
0460 5 460 600 2x350 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil
0520 5 520 700 3x4/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0590 5 590 800 3x250 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil
MR12
0650 5 650 2x400 4x4/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0730 5 730 2x500 4x300 1 AWG-350 kcmil 1 AWG-350 kcmil
0820 5 820 2x600 4x350 1 AWG-350 kcmil 1 AWG-350 kcmil
0920 5 920 2x600 6x4/0 1 AWG-350 kcmil 1 AWG-350 kcmil
1040 5 1040 2x600 6x250 1 AWG-350 kcmil 1 AWG-350 kcmil
1180 5 1180 2x700 6x300 1 AWG-350 kcmil 1 AWG-350 kcmil
POWER CABLING VACON · 53
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
6

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
