Vacon 100 flow Installation Manual

Table 18: The cable and fuse sizes for VACON
®
100 INDUSTRIAL and FLOW in North America,
mains voltage 525-690 V
Enclosure
size
Type IL [A] Fuse
(Class T/J)
[A]
Mains and
motor cable
(Cu) [AWG/
kcmil]
Terminal cable size
Mains cable
terminal [AWG/
kcmil]
Grounding
terminal [AWG/
kcmil]
MR8
0080 7 80.0 90 1/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0100 7 100.0 110 1/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0125 7 125.0 150 2/0 1 AWG-350 kcmil 1 AWG-350 kcmil
MR9
0144 7 144.0 175 3/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0170 7 170.0 200 4/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0208 7 208.0 250 300 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil
MR10
0261 7 261.0 350 2xAWG2/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0325 7 325.0 450 2x4/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0385 7 385.0 500 2x250 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil
0416 7 416.0 600 2x300 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil
MR12
0460 7 460 2x300 4x2/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0520 7 520 2x350 4x3/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0590 7 590 2x400 4x4/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0650 7 650 2x400 4x4/0 1 AWG-350 kcmil 1 AWG-350 kcmil
0750 7 750 2x450 4x300 1 AWG-350 kcmil 1 AWG-350 kcmil
0820 7 820 2x500 4x350 1 AWG-350 kcmil 1 AWG-350 kcmil
VACON · 54 POWER CABLING
6
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
