Vacon 100 flow Installation Manual

Table 19: Drive fuses in North America, 208-240 V and 380-500 V, Mersen
Enclosure
size
Type I
L
[A] Catalogue number of the
fuse
Fuse
rating
[A]
Number
of fuses
needed
Fuse
size
Minimum
prospective
short
circuit
current
MR8
0140 2
0140 5
140 PC30UD69V250TF 250 3 30 1550
0170 2
0170 5
170 PC30UD69V315TF 315 3 30 2250
0205 2
0205 5
205 PC30UD69V350TF 350 3 30 2250
MR9
0261 2
0261 5
261 PC30UD69V400TF 400 3 30 3100
0310 2
0310 5
310 PC30UD69V550TF 550 3 30 4700
MR10
0385 5 385 PC32UD69V630TF 630 3 32 4700
0460 5 460 PC32UD69V700TF 700 3 32 5700
0520 5 520 PC32UD69V900TF 900 3 32 8200
0590 5 590 PC32UD69V1000TF 1000 3 32 9600
MR12
0650 5 650 PC32UD69V630TF 630 6 32 4700
0730 5 730 PC32UD69V630TF 630 6 32 4700
0820 5 820 PC32UD69V700TF 700 6 32 5700
0920 5 920 PC32UD69V800TF 800 6 32 6800
1040 5 1040 PC32UD69V900TF 900 6 32 8200
1180 5 1180 PC32UD69V1000TF 1000 6 32 9600
POWER CABLING VACON · 55
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
6

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
