Vacon 100 flow Installation Manual

Table 20: Drive fuses in North America, 525-690 V, Mersen
Enclosure
size
Type I
L
[A] Catalogue number of the
fuse
Fuse
rating
[A]
Number
of fuses
needed
Fuse
size
Minimum
prospective
short
circuit
current
MR8
0080 7 80 PC30UD69V160TF 160 3 30 800
0100 7 100 PC30UD69V200TF 200 3 30 1200
0125 7 125 PC30UD69V250TF 250 3 30 1550
MR9
0144 7 144 PC30UD69V315TF 315 3 30 2250
0170 7 170 PC30UD69V315TF 315 3 30 2250
0208 7 208 PC30UD69V350TF 350 3 30 2550
MR10
0261 7 261 PC32UD69V450TF 450 3 32 3000
0325 7 325 PC32UD69V500TF 500 3 32 3400
0385 7 385 PC32UD69V630TF 630 3 32 4700
0416 7 416 PC32UD69V700TF 700 3 32 5700
MR12
0460 7 460 PC32UD69V450TF 450 6 32 3000
0520 7 520 PC32UD69V450TF 450 6 32 3000
0590 7 590 PC32UD69V500TF 500 6 32 3400
0650 7 650 PC32UD69V550TF 550 6 32 3900
0750 7 750 PC32UD69V630TF 630 6 32 4700
0820 7 820 PC32UD69V700TF 700 6 32 5700
VACON · 56 POWER CABLING
6
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
