6. Remove the battery casing.
7. Tighten the front loader frame bolts on the right hand side.
GUID-0ED3523C-9855-47AD-8BCF-28616B2B4975
1. Front loader frame bolt
The tightening torque is 600 Nm.
8. Fit the battery casing.
9. Connect the hoses and electric connectors to the windscreen washer fluid
reservoir.
10. Attach the main electric centre to the battery casing.
Tighten the 4 fastening screws.
11. Attach the engine electric centre to the battery casing.
12. Close the battery casing.
4. Maintenance
- 340 -
