13. Remove the cover plate on the AdBlue tank.
GUID-A9F264A3-4DC4-43C9-A1FB-2E24E437F772
1. Cover plate
2. Fastening screw
The cover plate is fastened with 3 screws.
14. Disconnect the electric connector and hoses from the tank heating sensor
cap.
GUID-74E79A4C-C414-4B59-AACC-5A37E901C14B
1. Tank heating sensor cap hoses
2. Electric connector
Plug the hoses.
4. Maintenance
- 341 -
