▪ HID/ProxIF 37-Bit
▪ XceedID 40-Bit
▪ Vanderbilt 35-bit (including EV1)
▪ MiFare 32-Bit Serial Number
▪ Communicates via RS-485 protocol
▪ Capable of running in degraded mode, allowing local decision making, if communication fails between the
Reader Interface and bright blue
▪ Can be powered directly from bright blue
▪ OPTIONAL - can be powered locally by a UL294 Listed Power-Limited, Power Supply capable of 4 hours
standby power.
Features
▪ Supports one read-head credential
▪ Connects directly to the communication channels on the bright blue controller via RS-485 protocol
▪ Two form C, single pole/double throw, 30 VDC mechanically latching relays:
K1 rated @ 5A; K2 rated @ 1A
▪ Two supervised or unsupervised contact inputs with the ability to support a wide range of end-of-line resistor
values
▪ Connection for one multi-color LED for access granted or access denied indication
▪ Connector for one buzzer/annunciator
Specifications
▪ Board Dimensions: 4.25” W x 2.75” L x 1” H (108mm x 70 mm x 24.6mm)
▪ Enclosure Dimensions: 8-1/4”H x 7-1/2W” x 3-1/2” D
▪ Power requirements: 12 – 24 VDC (supplied from bright blue or external Power Supply)
Warning: Input Power is passed directly to the Reader Head Terminal.
If the Reader Head Terminal is used to power the reader head, verify that the VRI-1 input voltage
is within the allowable range for the specific reader head connected.
▪ Power consumption: 50 - 150mA max (depending on input voltage)
▪ Ambient temperature: 0º to 49º C or 32º to 120º F
Enclosure
VRI-1 Enclosure – An enclosure with a hinged, screw-down door is included for each VRI-1 board. Tamper
switch, lock and key are available options.
Features
▪ Metal enclosure with hinged door
▪ Enclosure Dimensions: 8 1/4” x 7 1/2” x 3 1/2”
