146 bright blue Installation Manual
Contacts, Relays, and Pin Functions
A set of input contacts and output relays are provided on the Schlage VIP Lock. The locks can be ordered with
integrated credential readers.
Input Contacts
▪ Request to Exit (REX), normally open, non-supervised
▪ Door Open Detect (DOD), normally open, non-supervised
▪ Latch bolt monitor (LBM), normally closed, non-supervised
▪ Key position, normally closed, non-supervised
▪ Spare
Output Relays
▪ Solenoid for door strike
▪ Red Led Control
▪ Green Led Control
▪ Beeper Control
Credential Reader Technologies
▪ HID Proximity Credential
▪ Magnetic Stripe Credential
JP1 - RS-485 termination. This jumper must be removed to enable communication between VIP and bright blue.
J3 - Power source and communication. Used to connect bright blue to the VIP.
J6 - Not used.
Dip Switches
▪ 1-4 - Used for addressing the VIP. See the Addressing the VIP section for details.
▪ 5 - Used to choose between Fail Secure and Fail Safe
▪ OFF - Fail Secure (FSE)
▪ ON - Fail Safe (FSA)
▪ 6 - Used to choose between magstripe and proximity reader.
▪ OFF - Magstripe Reader
▪ ON - Proximity Reader
▪ 7 - Used to set protocol type. To communicate with bright blue this must be switched to ON.
▪ OFF - VIP protocol
▪ ON - 'F' series protocol
Note: Dip Switch 7 MUST be switched to the ON position for the VIP lock to work with bright blue.
