Wireless Panel Interface Module - PIM-SBB (Legacy)
The PIM-SBB (Legacy) works in conjunction with several types of wireless peripherals devices. The PIM-SBB
module is hard wired directly to the bright blue power and communication channels via RS-485 protocol. The
PIM-SBB can support up to 16 wireless devices.
Note: Only PIMs with firmware version 3.13 or higher are compatible with bright blue. Check the firmware
version by holding down the Reset button (S3) until the LEDs (CR6-10) start blinking. The red LEDs will blink first
and display the first part of the firmware version, then the green LEDs will blink displaying the second part of the
firmware version. Example: the reset button is pushed and the red LEDs blink 3 times then the green LEDs blink
13 times to indicate firmware version 3.13.
The PIM is capable of configuring (via laptop) the following items:
▪ Heartbeat interval
▪ Relock time
▪ Card format type
▪ Extended unlock
▪ Polarity of status signals
▪ Latch type
▪ Query intervals and quantity for unlock requests
▪ Cache mode
▪ Lock state in case of RF communication loss
▪ Relock action (timer only, door open or timer or door closed or timer card code conversions)
▪ Frequency agility for increased interference immunity
▪ Addressing - Automatic during Linking
Card formats
▪ The PIM-SBB accepts card formats up to 255 bits
Operational environment
▪ Temperature: -35°C to +66°C
▪ Humidity: 20% RH to 95% RH (non-condensing)
▪ Operating Voltage: 7.5 to 14.0 VDC. Powered from any data channel on the bright blue controller that is
supplying 12VDC or separately from UL listed power supply.
▪ Power consumption: 300mA max.
Radio frequency (RF) - The PIM includes an RF Transceiver
▪ Spread spectrum
▪ Direct sequencing spread spectrum
▪ Frequency: 902-928 MHz
▪ Data Rate: 62.5 kbps (half duplex)
▪ Modulo 256 error detection
▪ Approvals: FCC and RSS-210 (Canada)
▪ Transmitter Power: Up to 300mA
▪ Receiver Sensitivity: 90dBM typical
▪ Remote antenna modules - The PIM-SBB is capable of accommodating Remote Antenna Modules
Specifications for the PIM-SBB
