• Click the “+” / “Add Device” in the ENAGE app to find the Gateway.
• Select the Gateway. The Gateway LED will flash blue.
• Click “Yes”.
• Configure Device will open
• Name the Gateway and click Save / Next
• The next screen is used to configure the RS-485 address of the Gateway and the settings for the
Low Door address & High Door address (see addressing section above).
• Set the Gateway, Low Door and High Door Addresses
• Click “Save” – Commissioning is completed
• Click “Disconnect”
• The Gateway will now be displayed in the Connect to Device / Site screen
If the GWE – Gateway is not successfully commissioned and defined via the Android or iOS mobile device, the
Gateway will have to be reverted to the Schlage Factory Default settings prior to a 2
nd
attempt to commission.
See the Schlage GWE – Gateway Installation Instruction Guide for Factory Default Reset instructions.
