PaX-i (PCH-2500) User Manual
128
Appendices
Power
frequency
(50/60 Hz)
magnetic
eld
IEC 61000-
4-8
3 A/m 3 A/m Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
NOTE) U
T
is the a.c. mains voltage prior to application of the test level.
Guidance and manufacturer’s declaration - electromagnetic immunity
The model PaX-i(PCH-2500) is intended for use in the electromagnetic
environment specied below. The customer or the user of the model PaX-
i(PCH-2500) should assure that it is used in such an electromagnetic
environment
Immunity
test
IEC 60601
test level
Compliance
level
Electromagnetic
environment - guidance
Conducted
RF IEC
61000-4-6
Radiated RF
IEC 61000-
4-3
3 Vrms
150 kHz to
80MHz 3 V
/ m 80 MHz
to 2.5GHz
3 Vrms 150
kHz to 80
MHz 3 V / m
80 MHz to
2.5 GHz
The model PaX-
i(PCH-2500) must be
used only in a shielded
location with a minimum
RF shielding effectiveness
and, for each cable that
exits the shielded location,
a minimum RF filter
attenuation of 20 dB from
30 MHz to 230 MHz, 20 dB
from 230 MHz to 1 GHz.
Field strengths outside
the shielded location from
fixed RF transmitters,
as determined by an
electromagnetic site survey,
should be less than 3 V /
m.a Interference may occur
in the vicinity of equipment
marked with the following
symbol:
Pi_u272_en_20180514.indd 128 2018-05-14 오전 11:03:33
