BASIC SYSTEM PROGRAMMING TASKS DX-120 Programming Manual
- 96 -
Specifying PC-DBA Transmit Rate (continued)
SPECIFYING PC-DBA TRANSMIT RATE VIA THE DET
NOTE
• chg, bksp, save, one, always, del, and ack are interactive LCD button operations.
Use the three buttons below the LCD display to activate the associated operation.
• You can press Hold at any time to return to the previous level or press the volume
buttons to return to the main DB selection screen.
1) Enter Database Administration (see page 26) using the feature code Feature # * to display the password
prompt.
2) Enter the DB Admin password (see page 27).
3) Press show to display the DB Item Select screen.
4) Enter 04-16.
5) Press save to advance to the RTM XRATE field.
6) Press chg to select the transmission rate between your laptop and the switch.
7) Valid choices include 1200, 2400, 4800, 9800, and 19200.
8) The default is 9600.
9) Press save to store the settings.
10) Press the Hold button to return to the previous menu level.
OR
Press the Volume button (up or down) to return to the DB Item Selection screen.
OR
Exit programming (see “Exiting Database Administration” on page 27).
