- 155 -
DX-120 Programming Manual PROGRAMMING FOR THE OPTIONAL T1 AND ISDN (T1/PRI) CARDS
PROGRAMMING FOR THE
OPTIONAL T1 AND ISDN (T1/PRI) CARDS
Use the programming instructions in this section if you have installed either of the following optional cards on the
current system:
• T1 Card (see below)
OR
• ISDN (T1/PRI) Card (see 164)
Programming for an Optional T1 Card
The optional T1 card offers the capability for digital trunking as well as increases trunk capacity (i.e., to 40 when
including 16 analog CO lines). ANI, DID, DNIS, Ground Start, Loop Start, E&M Wink Start, and E&M Immediate Start
are supported with the T1.
HINT
Also see...
• “T1 Call Operation” on page 320
• “Appendix F - T1 Maintenance” on page 480
• “Appendix D - Trunk Directory Numbers” on page 475
PROGRAMMING FOR A T1 CARD VIA PC-DBA
From the PC-DBA main screen:
Programming for a T1 Card via PC-DBA (continued on next page)
To Next Page
