- 151 -
DX-120 Programming Manual BASIC CO LINE PROGRAMMING TASKS
Setting Up the Alternate CO Line Group via PC-DBA (continued)
3) Select/enter the information for the fields as described below:
NOTE
Set the same information for Alt CO Group 2 as needed.
4) Click the Update button to store the settings into the database on the local disk.
• Use the procedure above to program alternate CO Line Groups for other CO groups in the system.
When you have finished all programming changes:
5) Click the Close button to exit the current screen and return to the PC-DBA main screen.
6) Perform a SEND to copy the database changes to the DX-120 switch system memory.
Setting Up the Alternate CO Line Group (continued on next page)
IN THIS FIELD... DO THIS...
Alt CO Group 1
Select the first alternate CO group for the selected CO group.
• Valid alternate group numbers are line groups 0 through 8.
• The default is 0 (no alternate group).
Delete Digits
Select the number of digits you want the system to delete at the begin-
ning of the dial string when it uses this alternate route.
• Valid digits are 0-16.
• The default is 0 (delete no digits).
Inserted Digits
Enter the digits you want the system to insert at the beginning of the dial
string when it uses this alternate route.
• You can enter up to 16 digits using digits 0-9.
• The default is blank (insert no digits).
To Next Page
