PROGRAMMING FOR THE OPTIONAL T1 AND ISDN (T1/PRI) CARDS DX-120 Programming Manual
- 158 -
When you are finished:
3) Click the Update button to store the settings into the database on the local disk.
4) Click the Close button to exit the current screen and return to the PC-DBA main screen.
When you have finished all programming changes:
5) Perform a SEND to copy the database changes to the DX-120 switch system memory.
Programming for a T1 Card (continued on next page)
Alarm
• None
Channel Setting
DIR # NO
•
Channel Type
• Loop Start
• Ground Start
•DID
• Immed Start E&M
• Wink Start E&M (default)
• Loop Back
T1 Padding
•Rx Gain
- -12 to +12
•Tx Gain
- -12 to +12
Tie Line
(T1 Remote Ext)
Reserved for Future Use
*If you are programming an ISDN (T1/PRI) card,
make sure that this default is set.
T1 CARD PROGRAMMING FIELDS (continued)
IN THIS FIELD SELECT...
DX-120 Programming Manual
