SETTING UP UCD VOICE ANNOUNCE (VA) GROUPS DX-120 Programming Manual
- 360 -
Setting Up UCD VA Groups via the DET (continued)
Program the analog extension ports as type VA:
4) Enter 01-XXX-21 (where XXX is the extension number of the analog port connected to an ancillary RAD
Device).
5) Press save to display the corresponding extension Port Type screen.
6) Press chg to select VA.
7) Press the volume UP button to return to the DB Item Selection screen.
• Repeat steps 4 through 7 to set other analog extensions connected to RAD devices to port type V.A., as
needed.
8) Program your UCD group as described in Setting Up UCDs (see “Programming UCDs via the DET” on
page 349).
IMPORTANT!
• Be sure to program the UCD group number you want to use as the V.A. group.
Also be sure to assign V.A. in the Attribute field.
• In the overflow destination fields, enter the V.A. UCD group number.
9) Press the Hold button to return to the previous menu level.
OR
Press the Volume button (up or down) to return to the DB Item Selection screen.
OR
Exit programming (see “Exiting Database Administration” on page 27).
