- 403 -
DX-120 Programming Manual BASIC EXTENSION PROGRAMMING TASKS
Assigning Extensions to a Class of Service via the DET (continued)
Setting the Evening COS for an Extension:
From the DB Item Select screen (see steps 1 through 3 above):
4) Enter 01-XXX-06 (where XXX is the extension: 101~204).
5) Press chg until the COS you want to assign displays.
• Valid choices are 0 through 7.
• The default is class of service 0.
6) Press the volume UP button to return to the DB Item Selection screen.
HINT
Assign daytime and evening class of services to other extensions (as needed) using
the steps above.
OR
7) Press the Hold button to return to the previous menu level.
OR
Exit programming (see “Exiting Database Administration” on page 27).
